Moog DM2020 Series User Manual

Model/Code
CC130HNNLNNxxxx CC130JNNLNNxxxx CC140FDNLNxxxxx CC140FENLNxxxxx CC140FFNLNxxxxx
Mechanical dimensions 200 mm (7.87 inches)
Configuration Single Single Double Double Double
Type L200 L200 L200 L200 L200
Module current
@ 8 kHz
96 128 72 80 96
Arms rated current 96 - 128 - 48 24 48 32 48 48
Arms peak current 192 - 256 - 96 48 96 64 96 96
Cooling Incorporated ventilation
Weight 1 7. 5 1 7. 5 1 7. 5 1 7. 5 1 7. 5
Connector code BC7115R BC7115R BC7225R BC7225R BC7225R
Model/Code
CC140GSNLNxxxxx CC140GANLNxxxxx CC140GBNLNxxxxx CC140GCNLNxxxxx
Mechanical dimensions 200 mm (7.87 inches)
Configuration Double Double Double Double
Type L200 L200 L200 L200
Module current
@ 8 kHz
66 68 72 80
Arms rated current 64 2 64 4 64 8 64 16
Arms peak current 128 4 128 8 128 16 128 32
Cooling Incorporated ventilation
Weight 17. 5 1 7. 5 1 7. 5 1 7. 5
Connector code BC7226R BC7226R BC7226R BC7226R
PN: L-MAM2-E-201
Moog Casella DM2020 Installation and Startup Guide
3.1.3 DM2020 Standard Models
Model/Code
CC140GDNLNxxxxx CC140GENLNxxxxx CC140GFNLNxxxxx CC140GGNLNxxxxx
Mechanical dimensions 200 mm (7.87 inches)
Configuration Double Double Double Double
Type L200 L200 L200 L200
Module current
@ 8 kHz
88 96 112 128
Arms rated current 64 24 64 32 64 48 64 64
Arms peak current 128 48 128 64 128 96 128 128
Cooling Incorporated ventilation
Weight 17. 5 1 7. 5 1 7. 5 1 7. 5
Connector code BC7226R BC7226R BC7226R BC7226R
3.1.4.1 Models and coding auxiliary bus capacitor (ABC) modules
Model Code
Capacity (µF) Dimensions
DM2020 ABC5 CCE5000 5400
50 mm/1.97 inches
DM2020 ABC4 CCE5012 4500
DM2020 ABC3 CCE5013 3600
DM2020 ABC2 CCE5014 2700
DM2020 ABC1 CCE5015 1800
