Moog DM2020 Series

4.3.3 Dynamic Brake Unit Ratings
PN: L-MAM2-E-201
Moog Casella DM2020 Installation and Startup Guide
4.3.4 Dynamic Brake Unit Ratings
• The maximum current and the related duty cycle of the dynamic brake unit are as follows.
Model no.
Max current
amps
Max duty cycle (%)
Peak RMS
CC201(L50) 52.6 0.47 A 0.89 %
CC202(L150) 168 1.26 A 0.75 %
Please note: the Duty Cycle (D.C.) is referred to % of total time = 1 sec.
63
