12.2 Metric/AWG Conversion Table
AWG Diameter Cross-section
Ohmic
resistance at
20 °C
Weight
mils mm Circ. mils mm2 W/km g/m
44 2.0 0.50 4.00 0.0020 8498 0.0180
43 2.2 0.055 4.84 0.0025 7021 0.0218
42 2.5 0.063 6.25 0.0032 5446 0.0281
41 2.8 0.071 7.84 0.0039 4330 0.0352
40 3.1 0.079 9.61 0.0049 3540 0.0433
39 3.5 0.089 12.3 0.0062 2780 0.0552
38 4.0 0.102 16.0 0.0081 2130 0.0720
37 4.5 0.114 20.3 0.0103 1680 0.0912
36 5.0 0.127 25.0 0.0127 1360 0.1126
35 5.6 0.142 31.4 0.0159 1080 0.1412
34 6.3 0.160 39.7 0.0201 857 0.1785
33 7.1 0.180 50.4 0.0255 675 0.2276
32 8.0 0.203 64.0 0.0324 532 0.2886
31 8.9 0.226 79.2 0.0401 430 0.3571
30 10.0 0.254 100 0.0507 340 0.4508
29 11.3 0.287 128 0.0649 266 0.5758
28 12.6 0.320 159 0.0806 214 0.7157
27 14.2 0.361 202 0.102 169 0.9076
26 15.9 0.404 253 0.128 135 1.1383
25 17.9 0.455 320 0.162 106 1.4433
24 20.1 0.511 404 0.205 84.2 1.8153
23 22.6 0.574 511 0.259 66.6 2.3064
22 25.3 0.643 640 0.324 53.2 2.8867
21 28.5 0.724 812 0.411 41.9 3.6604
20 32.0 0.813 1020 0.519 33.2 4.6128
19 35.9 0.912 1290 0.653 26.4 5.8032
18 40.3 1.02 1620 0.823 21.0 7.3209
17 45.3 1.15 2050 1.04 16.6 9.2404
16 50.8 1.29 2580 1.31 13.2 11.6212
15 57.1 1.45 3260 1.65 10.4 14.6885
14 64.1 1.63 4110 2.08 8.28 18.4512
13 72.0 1.83 5180 2.63 6.56 23.3616
12 80.8 2.05 6530 3.31 5.21 29.4624
11 90.7 2.30 8230 4.17 4.14 37.0512
PN: L-MAM2-E-201
Moog Casella DM2020 Installation and Startup Guide
13.2 Metric/AWG Conversion Table
