AWG Diameter Cross-section
Ohmic
resistance at
20 °C
Weight
mils mm Circ. mils mm2 W/km g/m
10 101.9 2.588 10380 5.26 3.277 46.7232
9 114.4 2.906 13090 6.63 2.600 58.9248
8 125.5 3.264 16510 8.37 2.061 74.4000
7 114.3 3.655 20820 10.55 1.634 93.744
6 162.0 4.115 26240 13.30 1.296 118.1472
5 181.9 4.620 33090 16.77 1.028 148.8
4 204.3 5.189 41740 21.15 0.8152 187.488
3 229.4 5.287 52260 26.67 0.6466 235.592
2 257.6 6.543 66360 33.62 0.5128 299.088
1 289.3 7.348 83690 42.41 0.4065 376.464
1/0 324.9 8.252 105600 53.49 0.3223 474.672
2/0 364.8 9.266 133100 67.43 0.2557 599.664
3/0 409.6 10.40 167800 85.01 0.2028 755.904
4/0 460.0 11.68 211600 107.22 0.1608 953.808
PN: L-MAM2-E-201
Moog Casella DM2020 Installation and Startup Guide
13.2 Metric/AWG Conversion Table
