3.1.6 Power supply units coding
PN: L-MAM2-E-201
Moog Casella DM2020 Installation and Startup Guide
3.1.5 Connector Kits
Version
2 Standard model
E Special model
X Test model
Mechanical hardware conig uration
Value Power supply
model
Width Rated current (CC)
00 DM2020-PS “S”
50 mm/
1.97 inches
32 Arms/90 Apk
01 DM2020-PS “M”
50 mm/
1.97 inches
54 Arms/130 Apk
02 DM2020-PS “L”
150 mm/
5.90 inches
128 Arms/256 Apk
OPT1 - Special coni gurations
Value - Internal coding (
4
)
Value Version
00 Standard
OPT2 - Special coni gurations
Value - Internal coding (
4
)
Value Version
00 Standard
C0
Conformal coating for
standard “00” configuration
50
UL LISTED for standard “00”
configuration
L0
- Conformal coating for version
“50”
Hardware revision
Value - Internal coding (
4
)
Value Power supply model
A DM2020-PS “L”
B DM2020-PS “S”
DM2020-PS “M”
Special variations
Value - Internal coding (
4
)
Value Description
01
Special Reg. Res. (16 ohm/500 W
Armoured)
02
With power connectors & without
R.R. on kit
03
With power connectors &
Special Reg. Res. (18 ohm/350 W
armoured)
C
C -
(
4
) Values assigned by Moog
The first two characters are “CC” and indicate the
family (DM2020).
Example: The code CC201A0000 identifies the
standard power supply available in 54 A DC in the
final production version without special versions.
