Moog Casella DM2020 Installation and Startup Guide

3.2.4.1 Connector Layout

X21

X20

X18

X19

Module L200 double axis: front (A) and bottom (B) view.

Note that the arrangement of the front connector remains unchanged as in L50, L75 and

L100 modules (See previous page for details)

(A)

(B)
