Symbol Explanation
Thermal hazard alert symbol.
Mechanical hazard alert symbol.
General hazard alert symbol.
Notes about important operations and other useful information.
Ø
This is an action to be carried out.
● / -
This is a bullet list.
1., 2., ... These are steps in a procedure that must be performed in consecutive order.
The following table shows the abbreviations adopted in Moog documents:
Abbreviation Explanation
EMA Electro Mechanical Actuator
EH Electro Hydraulic Actuator
EHA Electro Hydrostatic Actuator
PN: L-MAM2-E-201
Moog Casella DM2020 Installation and Startup Guide
