MOOR INSTRUMENTS moorLDI2 RESEARCH USER MANUAL

136

1.5 If the serial number box is blank or the serial number displayed is incorrect, re-enter the correct serial

number in the appropriate box and click the small right arrow button to the right of the Serial Number

box. Confirm that the correct settings are entered by clicking on ‘Get sets’ again.

Get Sets

Serial

Number

Arrow

Button
