MOOR INSTRUMENTS moorLDI2 RESEARCH USER MANUAL
12
1. Socket for mains lead 2. Fuses
3. ON/OFF switch 4. Fan
5. BNC output for devices (e.g MIC2) 6. Port 2: from scan head
7. RS232 lead to PC 8. Port 1: from scan head
9. IEEE 1394 Firewire to PC 10. Video from scan head
11. BNC input for devices (e.g. MIC2) 12. Ventilation Holes
FIGURE 2C - BACK PANEL OF THE CONTROL UNIT (FIREWIRE CAMERA MODEL)
SUPPLY FUSES 250v
220 - 240V 500 mA (T)
100 - 120V 1 A (T)
100 - 230V ~
50 - 60 Hz
50 VA
WARNING
ISOLATE MACHINE BEFORE REMOVING COVERS
ATTENTION
ISOLER MACHINE AVANT D'ENLEVER COUVERCLES
ACHTUNG
MASCINE ISOLIEREN BEVOR ENTFERNUNG DER DECKEL
AVISO
AISLE LA MAQUINA ANTES DE QUITAR
ATTENZIONE
ISOLARE MACCHINA PRIMA DI RIMOUVER COPERCHI
Port 1
Port 2O/P
Made in England by Moor Instruments Ltd Millwey, Axminster, Devon, EX13 5HU
Tel: +44 (0)1297 35715 Fax: +44 (0)1297 35716
www.moor.co.uk
CB SnDom Model
4 7
8
6
532
1
!
IEEE
1394
I/PVideo
9
10 11
0120
12
