MOOR INSTRUMENTS moorLDI2 RESEARCH USER MANUAL

FIGURE 3G – BACK OF THE SCAN HEAD AND CONNECTING CABLES

(FIREWIRE CAMERA MODEL)

Power cable RS232 lead

Firewire Cable

FIGURE 3H – PC CONNECTION CABLES (FIREWIRE CAMERA MODEL)

25 way screened

cable

8 way

connector

Video

cable
