F1: Program Mode
5-21
MASS 524 CMR FIRE CODE? This option is only available if the “FIRE SVCE. CODE”
option is set to “A17.1 - 2000". If this option is set to YES, the ASME A17.1-2000 fire code will
conform to the Massachusetts 524 CMR requirements. If this option is set to NO, the controller
will conform to the standard ASME A17.1-2000 code.
ASME A17.1A 2000 ADDENDA? Set to the appropriate addenda for your jurisdic-
tion. (2005, 2007, NONE)
DISABLE DPM ON FIRE PH.2? If Yes, Door Position Monitoring is disabled when the
car is on In-Car Firefighter operation (Fire Phase 2). If No, DPM is not disabled on Fire Phase 2.
LOW VOLTAGE FIRE SENSORS? If the fire sensors on this job use 24V signal levels,
set this option to Yes. If set to No, the signal level is assumed to be 120 VAC.
FIRE HAT STATUS?
1
Dynamic/Latch Flashing/Latch Initial.
• Dynamic: Regardless of which fire alarm initiating device (FAID) initiated Fire Phase I
operation, whenever the FAID in the elevator machine room or hoistway is activated, the
fire hat in the associated car will flash. Otherwise, the fire hat will illuminate solidly unless
required by code to flash in response to some other, non-FAID device actuation (for exam-
ple, battery rescue device, low oil, etc.).
• Latch Flashing: Regardless of which fire alarm initiating device (FAID) initiated Fire
Phase I operation, once the FAID in the elevator machine room or hoistway is activated,
the fire hat in the associated car will flash and remain flashing throughout fire service.
• Latch Initial: If the fire alarm initiating device (FAID) that initiated Fire Phase I is located
in the elevator machine room or hoistway, the fire hat in the associated car will flash and
remain flashing throughout fire service. Otherwise, the fire hat will illuminate solidly and
remain so throughout fire service unless required by code to flash in response to some
other, non-FAID device actuation (for example, battery rescue device, low oil, etc.). This
option should be selected for ASME A17.1-2004/CSA B44-04 and later.
1. A17.1/B44 code edition/addenda or jurisdiction dependent: (A) for ASME A17.1-2004/CSA B44-04 and later,
the machine room or hoistway sensor must be the sensor that initiated Fire Phase I for the hat to flash; or (B) for
earlier editions of A17.1/B44, the fire hat will flash any time the machine room or hoistway sensor is active,
regardless of which device initiated Fire Phase I. Also, some jurisdictions occasionally modify the A17.1/B44
requirements, so please consult with the jurisdictional authorities for additional requirements.
