132 Floor height in counts
133 DLM edge in counts
134 ULM_edge in counts
140 Front Floor 14 Floor height (inch or mm)
141 Measured magnet length in counts
142 Floor height in counts
143 DLM edge in counts
144 ULM_edge in counts
150 Front Floor 15 Floor height (inch or mm)
151 Measured magnet length in counts
152 Floor height in counts
153 DLM edge in counts
154 ULM_edge in counts
160 Front Floor 16 Floor height (inch or mm)
161 Measured magnet length in counts
162 Floor height in counts
163 DLM edge in counts
164 ULM_edge in counts
Addresses 170 through 644 are not applicable to a hydro controller.
650 Rear Floor 1 Floor height (inch or mm)
651 Measured magnet length in counts
652 Floor height in counts
653 DLM edge in counts
654 ULM_edge in counts
660 Rear Floor 2 Floor height (inch or mm)
661 Measured magnet length in counts
662 Floor height in counts
663 DLM edge in counts
664 ULM_edge in counts
670 Rear Floor 3 Floor height (inch or mm)
671 Measured magnet length in counts
672 Floor height in counts
673 DLM edge in counts
674 ULM_edge in counts
Table 5.13 LS-EDGE Diagnostics
Address Floor number Diagnostic
