F5: Controller Utilities/Monitoring and Reporting
5-93
116
Port G outputs:
01 = (n/a)
02 = (n/a)
03 = (n/a)
04 = (n/a)
05 = (n/a)
06 = (n/a)
07 = (n/a)
08 = (n/a)
09 = (n/a)
10 = (n/a)
11 = (n/a)
12 = (n/a)
13 = DIA1
14 = DIA2
15 = DIA3
16 = DIA4
200
Faults (01 - 16):
01 = Maximum position offset fault
02 = Minimum position offset fault
03 = Landing system communication loss fault
04 = Excessive faults shutdown
05 = FCL-3 is offline
06 = FCL-4 is offline
07 = Landing system ETS fault
08 =LS-EDGE CPU-B is offline
09 = Inspection over-speed
10 = Contract over-speed
11 = Leveling over-speed
12 = Up normal limit open
13 = Down normal limit open
14 = ETS shutdown
15 = UETS over-speed
16 = UETS position error
201
Faults (17 - 32):
01 = DETS over-speed
02 = DETS position error
03 = Drive not ready
04 = Drive fault
05 = Drive on fault
06 = EEPROM error (CRC / device)
07 = Incorrect landing system channel detected
08 = Actual and requested direction mismatch
09 = UNTS-L over-speed
10 = UNTS-H over-speed
11 = UNTS position error
12 = DNTS-L over-speed
13 = DNTS-H over-speed
14 = DNTS position error
15 = Landing system floor checksum error
16 = Landing system ETS checksum error
Table 5.15 Controller Board CTL B Processor Diagnostics
Address Item Notes
