F7: Parameters Adjust

5-105

Stepping System, 208 [SINGLE or DUAL]. Set to Dual if both stepping and sub-step-

ping are used. Set to single if only stepping is used.

• SINGLE - - If this option is selected, only STEP UP / STEP DN parameters will be visible

and adjustable by the user. These parameters apply for both one-floor-runs and multi-

floor-runs.

• DUAL - If this option is selected, both the STEP UP / STEP DN and SUB-STEP UP / SUB-

STEP DN parameters will be visible. The STEP UP / STEP DN parameters are used for

multi-floor-runs while SUB-STEP UP / SUB-STEP DN parameters are used for one-floor-

runs.

Step Down x, 209, 211, 213, etc. This parameter is the down stepping distance

for floor 1, 2, 3, etc. When the SINGLE stepping system is selected, this parameter represents

the slowdown distance to floor “x” from above for both a one-floor-run and multi-floor-runs. If

the “DUAL” stepping system is selected, this parameter represents the slowdown distance to

floor “x” from above for multi-floor-runs.

Step Up x, 210, 212, 214, etc. This parameter is the up stepping distance for floor

1, 2, 3, etc. When the SINGLE stepping system is selected, this parameter represents the slow-

down distance to floor “x” from below for both a one-floor-run and multi-floor-runs. If the

“DUAL” stepping system is selected, this parameter represents the slowdown distance to floor

“x” from below for multi-floor-runs.

Sub-step Down x, 241, 243, 245, etc. Stepping distance when the car is one floor

away. When the DUAL stepping system is selected, this parameter represents the slowdown

distance to floor “x” from above for a one-floor-run. If the distance for this parameter is the

same as the associated STEP DN x parameter, a zero distance or the STEP DN x distance should

be entered.

Sub-step Up x, 242, 244, 246, etc. Stepping distance when the car is one floor

away. When the DUAL stepping system is selected, this parameter represents the slowdown

distance to the floor from below for a one-floor-run. If the distance for this parameter is the

same as the associated STEP UP x parameter, a zero distance or the STEP UP x distance should

be entered.

Motion Control Engineering 2000 User Manual
