Motion 2000 TSSA Description
1-8 Manual # 42-02-1P21
HC-CTL-2 Main Control Board Monitors I/O, performs safety functions and front
door operation. Please refer to “HC-CTL-2 Main Control Board” on page 1-7. The HC-CTL-2
board is responsible for inspection, fire service, landing system, door lock bypass and lanterns
and gongs. For more information see “HC-CTL Control Board” on page 6-40.
CE Fixture boards with LON interface (not shown) Used when extensive exter-
nal fixtures are required.
MC-CPI or ICE-COP-2 Car Panel Interface Board (not shown) Converts the
Discrete closures from car panel buttons and switches to CAN data and passes it through the
Landing System Interface board (MC-LSI) to the car controller or dispatcher (see “ICE-COP-2
Car Panel Interface Board” on page 6-60).
MC-LSI Landing System Interface Board (not shown) Provides a connection
point for the Car Panel Interface board (MC-CPI or ICE-COP-2). A shielded external CAN con-
nection runs from the MC-LSI board, through the traveler, to the Motion 2000 controller (see
“Example: MC-CPI Wiring” on page 6-67).
