LCD Controller
MOTOROLA MPC823e REFERENCE MANUAL 18-37
LCD CONTROLLER
18
18.4.8 LCD Panel Connection Examples
Some panels connect differently than the MPC823e. These panels are shown as examples
in Table 18-4 and they may or may not be currently available.
Table 18-4. LCD Panel Connection
MPC823e
SIGNAL
(PORT PIN)
DISPLAY TYPES
SHARP
LQ9D021
ACTIVE
COLOR
GENERIC
PASSIVE COLOR
SHARP
LM64P839
PASSIVE
MONOCHROME
DUAL-SCAN
HITACHI
LMG7211URFR
PASSIVE
MONOCHROME
SHARP
LM32K07
PASSIVE
MONOCHROME
SHARP
LQ10D131
COLOR
ACTIVE
SHIFT/CLK (PD3) CK-P[10] — CP2-P[3] CL2-P[3] CP2-P [10] CK-P[10]
LOAD/HSYNC (PD4) HSYNC-P[6] — CP1-P[2] CL1-P[2] CP1-P [11] HSYNC-P[6]
FRAME/VSYNC (PD5) VSYNC-P[4] — S-P[1] FRAME-P[1] S-P [12] VSYNC-P[4]
LCD_AC/LOE (PD6) ENAB-P [28] — — — — ENAB-P[28]
LD0 (PD7) R2-P [7] — — — — R3-P[7]
LD1 (PD8) R1-P [5] D7 (MSB) DU3-P [11] — — R2-P[5]
LD2 (PD9) R0-P [3] D6 DU2-P [10] — — R1-P[3]
LCD_A (PB31) — — — — — R0-P[1]
LD3 (PD10) G2-P [19] D5 DU1-P[9] — — G3-P[19]
LD4 (PD11) G1-P [17] D4 DU0-P[8] — — G2-P[17]
LD5 (PD12) G0-P [13] D3 DL3-P [15] D3-P [11] D3-P [3] G1-P[13]
LCD_B (PB15) — — — — — G0-P[P11]
LD6 (PD13) B2-P [29] D2 DL2-P [14] D2-P [10] D2-P [4] B3-P[31]
LD7 (PD14) B1-P [27] D1 DL1-P [13] D1-P [9] D1-P [5] B2-P[29]
LD8 (PD15) B0-P [25] D0 (LSB) DL0-P [15] D0-P [8] D0-P [6] B1-P[25]
LCD_C (PB17) — — — — — B0-P[23]
