MOTOROLA MPC823e REFERENCE MANUAL 10-1
DATA CACHE
10
SECTION 10
DATA CACHE
The MPC823e data cache is a 8K two-way, set-associative cache. It is organized into 256
sets, two lines per set and four words per line. Cache lines are aligned on 4-word boundaries
in memory and can be used as an SRAM that allows the application to lock critical data
segments that need a fast and deterministic execution time. Two state bits are included in
each cache line and implement invalid, modified-valid, and unmodified-valid states of the
data cache. Cache coherency in a multiprocessor environment is maintained by the
software and supported by a fast hardware invalidation capability. The cache is designed for
both writeback and writethrough modes of operation and a least recently used (LRU)
replacement algorithm is used to select a line when no empty lines are available.
10.1 FEATURES
The following is a list of the data cache’s main features:
• 8K Four-Way, Set Associative, and Physically Addressed
• Single-Cycle Cache Access on Hit and 1 Clock Latency Added for Miss
• Four Word Line Size
• “Critical Word First” and Four Word Burst Line Fill
• Implements LRU Replacement Policy
• 32-Bit Interface to Load/Store Unit
• One-Word Write Buffer
• Lockable Cache Line Granularity
• Copyback/Writethrough Operation is Programmed per Memory Management Unit
Page
• Coherency is Only Maintained by the Software and No Bus Snooping is Supported
• Cache Operation is Blocked under Miss, until the Critical Word is Delivered to the Core
• Hit Under Miss Operation
• Full Data Cache PowerPC
™
Control Operations
• Implementation-Specific Single Operation
