16.8.3 UART Baud Rate Examples
For synchronous communication using the internal baud rate generator, the BRGOx output
clock must never be faster than the system frequency divided by 2. So, with a 25MHz
system frequency, the maximum BRGOx output clock rate is 12.5MHz. You must program
the UART to 16× oversampling when using a serial communication controller in UART
mode. On the MPC823e, 8× and 32× options are also available. Assuming 16×
oversampling is chosen in the UART, a data rate of 25MHz ÷ 16 = 1.5625Mb/sec is the
maximum possible UART speed. Putting this together, the following formula must be used
to calculate the bit rate based on a particular baud rate generator configuration for a UART:
async baud rate = (BRGCLK, CLK2 or CLK4) ÷ (clock divider + 1) ÷ (1 or 16
depending on the DIV16 bit) ÷ (8, 16, or 32 according to the
RDCR and TDCR fields in the GSMR_L register).
The following table lists typical bit rates of asynchronous communication. The internal clock
rate is assumed to be 16× the baud rate.
Table 16-23. Typical Baud Rates of Asynchronous Communication
BAUD
RATES
MPC823e SYSTEM FREQUENCY (MHz)
20 25 24.5760
DIV16 DIV ACTUAL
FREQUENCY
DIV16 DIV ACTUAL
FREQUENCY
DIV16 DIV ACTUAL
FREQUENCY
50 1 1561 50.02 1 1952 50 1 1919 50
75 1 1040 75.05 1 1301 75 1 1279 75
150 1 520 149.954 1 650 150 1 639 150
300 1 259 300.48 1 324 300.5 1 319 300
600 0 2082 600.09 0 2603 600 0 2559 600
1200 0 1040 1200.7 0 1301 1200 0 1279 1200
2400 0 520 2399.2 0 650 2400.1 0 639 2400
4800 0 259 4807.7 0 324 4807.69 0 319 4800
9600 0 129 9615.4 0 162 9585.9 0 159 9600
19200 0 64 19231 0 80 19290 0 79 19200
38400 0 32 37879 0 40 38109 0 39 38400
57600 0 21 56818 0 26 57870 0 26 56889
115200 0 10 113636 0 13 111607 0 12 118154
NOTE: All values are decimal.
