System Interface Unit
MOTOROLA MPC823e REFERENCE MANUAL 12-35
SYSTEM INTERFACE UNIT
12
MASKNUM—Mask Number
This read-only field is mask-programmed with a code corresponding to the mask number of
the part on which the system interface unit is located. It is intended to help with factory test
and user code that is sensitive to part refinements. As a result, the value of this field depends
on the mask revision.
12.12.1.3 SYSTEM PROTECTION CONTROL REGISTER. The system protection control
register (SYPCR) controls the system monitors, software watchdog period, and bus monitor
timing. This register can be read at any time, but can only be written once after system reset.
SWTC—Software Watchdog Timer Count
This field contains the count value for the software watchdog timer.
BME—Bus Monitor Enable
This bit controls the operation of the bus monitor when an internal to external bus cycle is
executed.
0 = Disable the bus monitor.
1 = Enable the bus monitor.
BMT—Bus Monitor Timing
This field defines the timeout period, in 8 system clock resolution, for the bus monitor. The
maximum timeout is 2,040 clocks.
Bits 25–27—Reserved
These bits are reserved and must be set to 0.
SYPCR
BIT 0 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15
FIELD
SWTC
RESET
1
R/W
R/W
ADDR (IMMR & 0xFFFF0000) + 0x004
BIT 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31
FIELD
BMT BME RESERVED SWF SWE SWRI SWP
RESET
1 0 0 0111
R/W
R/W R/W R/W R/W R/W R/W R/W
ADDR (IMMR & 0xFFFF0000) + 0x006
Note: If the bus monitor is disabled, the transfer error conditions will not assert the
TEA
pin.
