12.8.2 Periodic Interrupt Timer Count Register
The read/write periodic interrupt timer count (PITC) register contains a 16-bit value that will
be loaded into the periodic interrupt down counter.
PITC—Periodic Interrupt Timer Count
This field contains the count for the periodic timer. If this field is loaded with the value
0xFFFF, the maximum count period will be selected.
Bits 16–31—Reserved
These bits are reserved and must be set to 0.
PITC
BIT 0 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15
FIELD PITC
RESET —
R/W R/W
ADDR (IMMR & 0xFFFF0000) + 0x244
BIT 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31
FIELD RESERVED
RESET 0
R/W R/W
ADDR (IMMR & 0xFFFF0000) + 0x246
NOTE: — = Undefined.
