MOTOROLA MPC823e REFERENCE MANUAL 12-9
SYSTEM INTERFACE UNIT
12
LVM—Level Mask 0–7
When set, these bits enable a LEVELx interrupt request from an internal source to be
generated. The SIPEND register contains the corresponding LVLx bits. See Figure 12-2 for
more information.
0 = Disable the generation of an IRQx bit in the SIPEND register.
1= Enable the generation of an IRQx bit in the SIPEND register.
Bits 16–31—Reserved
These bits are reserved and must be set to 0.
12.3.3.3 SIU INTERRUPT EDGE/LEVEL REGISTER. The 32-bit read/write SIU interrupt
edge/level (SIEL) register contains pairs of bits that correspond to an external interrupt
request. If set, the EDx bit specifies when a falling edge in the corresponding IRQx
signal is
an interrupt request. When the EDx bit is 0, a low logical level in the IRQx
signal is an
interrupt request. The WMx bit, if set, indicates that a low level detection in the
corresponding interrupt request line causes the MPC823e to exit low-power mode.
ED—Edge Detect 0–7
0 = The bits specify that a low logical level in the IRQx
signal is detected as an interrupt
request.
1 = The bits specify that a falling edge in the corresponding IRQx
signal is detected as
an interrupt request.
WM—Wake-Up Mask 0–7
0 = Not allowed to exit from low-power mode.
1 = Allows low-level detection in the corresponding IRQx
signal to exit or wake up the
MPC823e from low-power mode.
SIEL
BIT
0 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15
FIELD ED0 WM0 ED1 WM1 ED2 WM2 ED3 WM3 ED4 WM4 ED5 WM5 ED6 WM6 ED7 WM7
RESET 0000000000000000
R/W R/W R/W R/W R/W R/W R/W R/W R/W R/W R/W R/W R/W R/W R/W R/W R/W
ADDR (IMMR & 0xFFFF0000) + 0x018
BIT
16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31
FIELD RESERVED
RESET 0
R/W R/W
ADDR (IMMR & 0xFFFF0000) + 0x018
