Development Capabilities and Interface
MOTOROLA MPC823e REFERENCE MANUAL 20-43
DEVELOPMENT
20
CAPABILITIES & INTERFACE
20.6.2.2 COMPARATOR E–F VALUE REGISTERS. The comparator E-F value (CMPE-F)
registers contain the address to be compared to the load/store address for generating a
load/store watchpoint. These registers have an undefined reset value.
LCMPV—Load/Store Comparison Value
This field is the address bits to be compared to the load/store address.
CMPE-F
BIT 0 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15
FIELD LCMPV
RESET X
R/W R/W
SPR 152, 153
BIT 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31
FIELD LCMPV
RESET X
R/W R/W
SPR 152, 153
NOTE: X = “Don’t Care”.
