Development Capabilities and Interface
20-48 MPC823e REFERENCE MANUAL MOTOROLA
DEVELOPMENT
20
CAPABILITIES & INTERFACE
20.6.2.6 LOAD/STORE SUPPORT COMPARATORS CONTROL REGISTER. The
load/store support comparators control (LCTRL1) register controls the load/store breakpoint
and watchpoint operation.
CTE—Compare Type, Comparator E
0xx = Not active (reset value).
100 = Equal to.
101 = Less than.
110 = Greater than.
111 = Not equal to.
CTF—Compare Type, Comparator F
0xx = Not active (reset value).
100 = Equal to.
101 = Less than.
110 = Greater than.
111 = Not equal to.
CTG—Compare Type, Comparator G
0xx = Not active (reset value).
100 = Equal to.
101 = Less than.
110 = Greater than.
111 = Not equal to.
LCTRL1
BIT 0 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15
FIELD
CTE CTF CTG CTH CRWE CRWF
RESET
00 0 000
R/W
R/W R/W R/W R/W R/W R/W
SPR
156
BIT 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31
FIELD
CSG CSH SUSG SUSH CGBMSK CHBMSK RESERVED
RESET
0000 0 0 0
R/W
R/W R/W R/W R/W R/W R/W R/W
SPR
156
