IEEE 1149.1 Test Access Port
MOTOROLA MPC823e REFERENCE MANUAL 21-7
IEEE 1149.1 TEST
21
ACCESS PORT
Table 21-1. Boundary Scan Bit Definition
BIT CELL TYPE PIN/CELL NAME PIN TYPE OUTPUT
CTL CELL
1 i.obs PB[26] IO —
2 o.pin PB[26] IO g56.ctl
3 IO.ctl G56.CTL — —
4 i.obs PC[12] IO —
5 o.pin PC[12] IO g34.ctl
6 IO.ctl G34.CTL — —
7 i.obs PA[12] IO —
8 o.pin PA[12] IO g74.ctl
9 IO.ctl G74.CTL — —
10 i.obs PB[27] IO —
11 o.pin PB[27] IO g57.ctl
12 IO.ctl G57.CTL — —
13 i.obs PC[13] IO —
14 o.pin PC[13] IO g35.ctl
15 IO.ctl G35.CTL — —
16 i.obs PA[13] IO —
17 o.pin PA[13] IO g75.ctl
18 IO.ctl G75.CTL — —
19 i.obs PB[28] IO —
20 o.pin PB[28] IO g58.ctl
21 IO.ctl G58.CTL — —
22 i.obs PC[14] IO —
23 o.pin PC[14] IO g36.ctl
24 IO.ctl G36.CTL — —
25 i.obs PA[14] IO —
26 o.pin PA[14] IO g76.ctl
27 IO.ctl G76.CTL — —
28 i.obs PB[29] IO —
29 o.pin PB[29] IO g59.ctl
30 IO.ctl G59.CTL — —
31 i.obs PC[15] IO —
32 o.pin PC[15] IO g37.ctl
