Instruction Cache
MOTOROLA MPC823e REFERENCE MANUAL 9-13
INSTRUCTION CACHE
9
WORD—Word Select
This field is used to select a word within a set and way.
Bits 30–31—Reserved
These bits are reserved and must be set to 0.
When read from the data array, the 32 bits of the word selected by the IC_ADR is placed in
the targeted general-purpose register. When read from the tag array, the 22 bits of the tag
and related information that is selected by the IC_ADR are all placed in the targeted
general-purpose register. The following table provides the bit layout of the instruction cache
data register when reading a tag.
TAG—Tag Select
This field contains the upper 22 bits of the address.
Bits 20-21 and 30-31—Reserved
These bits are reserved and must be set to 0.
V—Valid Entry
0 = Entry is not valid.
1 = Entry is valid.
L—Lock Entry
0 = Entry is unlocked.
1 = Entry is locked.
IC_DAT (TAG READ FORMAT)
BIT 0 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15
FIELD TAG
RESET —
R/W R/W
SPR 562
BIT 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31
FIELD TAG RES V L LRU RES
RESET ———— — —
R/W R/W R/W R/W R/W R R/W
SPR 562
NOTE: — = Undefined.
