External Signals
MOTOROLA
MPC823e REFERENCE MANUAL
2-15
EXTERNAL SIGNALS
2
CHIP SELECT PINS
CS0
D12
CS1
A14
CS2
B14
CS3
A15
CS4
B16
CS5
D13
CS6
C14
CS7
B15
POWER SUPPLY PINS
VDDH
E5–12, F5, F12,
G5, G12, H5, H12,
J5, J12, K5, K12,
L5, L12,
M5–M12
VDDL
A7, G1, J16, T7
VDDSYN
B1
KAPWR
A3
VSSSYN
A1
VSSSYN1
A2
GND
F6–F11, G6–G11,
H6–H11, J6–J11,
K6–K11, L6–L11
NO CONNECT PINS
N/C
A16, C1, C6, E14,
J13, N9, N13,
P1, P10
Table 2-2. Pin Breakout (Continued)
SIGNAL
PIN NUMBER
75
77
