Memory Map
3-10 MPC823e REFERENCE MANUAL MOTOROLA
MEMORY MAP
3
A50 SCCE—SCC3 Event Register 16 16-187
16-227 (UART)
16-250 (HDLC)
16-284 (AHDLC)
16-314 (Trans)
A52-A53 Reserved 16 —
A54 SCCM—SCC3 Mask Register 16 16-187
16-229 (UART)
16-253 (HDLC)
16-316 (Trans)
A56 Reserved 8 —
A57 SCCS—SCC3 Status Register 8 16-187
16-230 (UART)
16-254 (HDLC)
16-316 (Trans)
A58-A81 Reserved — —
SERIAL MANAGEMENT CONTROLLER 1
A82 SMCMR—SMC Mode Register 16 16-384
16-398 (UART)
16-416 (Trans)
16-431 (GCI)
A84 RES—Reserved 16 —
A86 SMCE—SMC Event Register 8 16-405 (UART)
16-422 (Trans)
16-432 (GCI)
A87 to A89 RES—Reserved — —
A8A SMCM—SMC Mask Register 8 16-407 (UART
16-423 (Trans)
16-433 (GCI)
A8B to A91 RES—Reserved — —
SERIAL MANAGEMENT CONTROLLER 2
A92 SMCMR—SMC Mode Register 16 16-384
16-398 (UART)
16-416 (Trans)
16-431 (GCI)
A94 RES—Reserved 16 —
A96 SMCE—SMC Event Register 8 16-405 (UART)
16-422 (Trans)
16-432 (GCI)
A97 to A99 RES—Reserved — —
A9A SMCM—SMC Mask Register 8 16-407 (UART
16-423 (Trans)
16-433 (GCI)
A9B to A9F RES—Reserved — —
Table 3-1. MPC823e Internal Memory Map (Continued)
INTERNAL
ADDRESS REGISTER
SIZE
(IN BITS)
PAGE NUMBER
LOCATION
