Communication Processor Module
MOTOROLA MPC823e REFERENCE MANUAL 16-445
SPI
COMMUNICATION
16
PROCESSOR MODULE
PM—Prescale Modulus Select
This field specifies the divide ratio of the prescale divider in the SPI clock generator. The
BRGCLK is divided by 4 * ([PM0–PM3] + 1), thus giving a clock divide ratio of 4 to 64. The
clock has a 50% duty cycle.
16.12.4.1.1 SPI Examples With Different LEN Values. The programming examples
below illustrate the effect of the LEN field and the REV bit in the SPMODE register on output
from the SPI controller. They illustrate the master mode output from the SPI controller as the
LEN varies. To help map the output process, make
g through v the binary symbols, use x to
indicate a deleted bit, use __ to indicate original byte boundaries, and use _ to indicate
original nibble (4-bit) boundaries.
The initial pattern for all examples is ghij_klmn__opqr_stuv.
Example 1
LEN = 0x4 (Data Size = 5)
Data Selected: xxxj_klmn_xxxr_stuv
Data Transmitted for REV=0: nmlk_j__vuts_r
Data Transmitted for REV=1: j_nmlk__r_stuv
Example 2 LEN = 0x7 (Data Size = 8)
Data Selected: ghij_klmn_opqr_stuv
Data Transmitted for REV=0: nmlk_jihg__vuts_rqpo
Data Transmitted for REV=1: ghij_klmn__opqr_stuv
Example 3 LEN = 0xc (Data Size = 13)
Data Selected: ghij_klmn_xxxr_stuv
Data Transmitted for REV=0: nmlk_jihg__vuts_r
Data Transmitted for REV=1: r_stuv__ghij_klmn
Example 4 LEN = 0xf (Data Size = 16)
Data Selected: ghij_klmn_opqr_stuv
Data Transmitted for REV=0: nmlk_jihg__vuts_rqpo
Data Transmitted for REV=1: opqr_stuv__ghij_klmn
