Motorola MPC823e User Manual

PCMCIA Interface
17-20 MPC823e REFERENCE MANUAL MOTOROLA
PCMCIA INTERFACE
17
PSL—PCMCIA Strobe Length
This attribute determines the number of cycles the strobe will be asserted during a PCMCIA
access for this window. It is the main parameter for determining the length of the cycle. The
cycle may be lengthened by asserting the WAIT
signal.
00001=Strobe asserted 1 clock cycle.
00010=Strobe asserted 2 clock cycles.
00011=Strobe asserted 3 clock cycles.
00100=Strobe asserted 4 clock cycles.
00101=Strobe asserted 5 clock cycles.
00110=Strobe asserted 6 clock cycles.
00111=Strobe asserted 7 clock cycles.
01000=Strobe asserted 8 clock cycles.
01001=Strobe asserted 9 clock cycles.
01010=Strobe asserted 10 clock cycles.
01011=Strobe asserted 11 clock cycles.
01100=Strobe asserted 12 clock cycles.
01101=Strobe asserted 13 clock cycles.
01110=Strobe asserted 14 clock cycles.
01111=Strobe asserted 15 clock cycles.
10000=Strobe asserted 16 clock cycles.
10001=Strobe asserted 17 clock cycles.
10010=Strobe asserted 18 clock cycles.
10011=Strobe asserted 19 clock cycles.
10100=Strobe asserted 20 clock cycles.
10101=Strobe asserted 21 clock cycles.
10110=Strobe asserted 22 clock cycles.
10111=Strobe asserted 23 clock cycles.
11000=Strobe asserted 24 clock cycles.
11001=Strobe asserted 25 clock cycles.
11010=Strobe asserted 26 clock cycles.
11011=Strobe asserted 27 clock cycles.
11100=Strobe asserted 28 clock cycles.
11101=Strobe asserted 29 clock cycles.
11110=Strobe asserted 30 clock cycles.
11111=Strobe asserted 31 clock cycles.
00000=Strobe asserted 32 clock cycles.
PPS—PCMCIA Port Size
This field specifies the port size of this PCMCIA window.
0 = 8-bit port size.
1 = 16-bit port size.
