SERVICE MTSX RSS
4-18 68P81074C50
4.2.2.1 FRONT END FILTER ALIGNMENT
RSS LOCATION: At the SERVICE MENU, press .
Refer to your radio service manual for the front end filter alignment procedure. This procedure should only be
attempted by qualified service personnel.
FUNCTION KEY DESCRIPTIONS:
F1 - HELP provides useful information about the currently displayed menu, screen, or field.
F8 - PROGRAM VALUE function will program the selected value into the radio.
F10 - EXIT moves the display backward in the RSS tree, one screen or menu at a time.
New Softpot Value Field Definition
This is the front end filter softpot value for this frequency. The status bar shows the relationship between this
setting and the minimum and maximum settings.
MOTOROLA Radio Service Software
MTSX Model:
...FRONT END FILTER (VHF & UHF ONLY)
Use UP/DOWN Arrows To Adjust Softpot.
FRONT END FILTER (VHF & UHF ONLY)
Current
Frequency
Value New Softpot Value
450.02500 0 0
465.22500 0 0
475.22500 0 0
484.97500 0 0
500.27500 0 0
511.97500 0 0
519.97500 0 0
F1
HELP
F2 F3 F4 F5 F6 F7 F8
PROGRAM
VALUE
F9 F10
EXIT
0
Min
255
Max
F3
F2
PROGRAMMING PROCEDURE:
1. Press F2 at the MAIN MENU. The SERVICE MENU appears.
2. Press F3. The RECEIVER ALIGNMENT (VHF & UHF ONLY) MENU appears.
3. Press F2. The FRONT END FILTER ALIGNMENT screen appears.
4. Press Tab to select the desired field, or press the desired function key (F1 - F10).
5. If a field is selected, press the up/down arrow keys to select choice or value.
