Motorola MT 2000 User Manual

MTSX RSS CHANGE/VIEW
68P81074C50 6-121
6.2.3.4.3 QUIK-CALL II SYSTEM
RSS LOCATION: At the CHANGE/VIEW MENU, press .
MOTOROLA Radio Service Software
MTSX Model:
...CONV:AUX: QUIK-CALL II SYSTEM
Enter or Scroll to Select System.
System.....................1
QUIK-CALL II SYSTEM
System Signalling Type ...................Motorola Decoder Option............................(1) A-B
Signalling Muting Type...........................AND
Initial Squelch Type .....................Quik Call
Reset Type.............................................Auto Tone Freq (Hz) Code
Auto Reset Carr Ovrd ....................Enabled A 288.5 138
Auto Reset Duration (sec).........................5 B 600.9 121
Decoder 1 Call Type ......................Individual
Decoder 2 Call Type ...........................Group
F1
HELP
F2
ADD
SYS
F3
PREV
SYS
F4
NEXT
SYS
F5
DELETE
SYS
F6 F7 F8 F9
MORE
OPTIONS
F10
EXIT
PROGRAMMING PROCEDURE:
1. Press F4 at the MAIN MENU. The CHANGE/VIEW MENU appears.
2. Press F6. The CONVENTIONAL MENU appears.
3. Press F7. The AUXILIARY SYSTEMS MENU appears.
4. Press F4. The QUIK-CALL II SYSTEM screen appears.
5. Press Tab to select the desired field, or press the desired function key (F1 - F10).
6. If a field is selected, press the UP/DOWN arrow keys to select choice or value.
F7
F6
F4
FUNCTION KEY DESCRIPTIONS:
F1 - HELP provides useful information about the currently displayed menu, screen, or field.
F2 - ADD SYS (Add System) allows you to add a system.
F3 - PREV SYS (Previous System) allows you to go to the system before the current one.
F4 - NEXT SYS (Next System) allows you to go to the system after the current one.
F5 - DELETE SYS (Delete System) allows you to delete a system.
F10 - EXIT moves the display backward in the RSS tree, one screen or menu at a time.
