MTSX RSS GETTING STARTED
68P81074C50 2-31
Next are the steps to specify the serial port you use for interfacing with the radio and RIB. The default port is
COM 1.
2.10.2 Setting a Communications Port
Table 2-11. Setting a Port
Instruction What to Type Explanation
1. Go to CONFIGURE COMPUTER
2. Go to the RIB field
3. Select a port
4. Test the port
5. Save this configuration
6. Exit screen when done
Press F3 at SERVICE SOFTWARE
CONFIGURATION MENU to go to
CONFIGURE COMPUTER.
Pressing Tab , Enter or Return advances to
the next field. Press Tab five times.
Use the arrow keys to scroll through the
available ports. Options are COM 1 or COM
2 on many computers. Some computers will
also have COM 3 and COM 4. Choose the
port where you will connect the computer-to-
RIB cable.
You can test the port by pressing F6, COM
TEST - if OK it will beep and in the
Instruction Area (see letter B in Figure 2-7)
of the screen the words “Communication
with the radio was successful” will appear.
F8 saves the field options on the screen.
“Configuration File Written Successfully”
appears in Instruction Area (B) of the
screen.
Press F10 to exit this screen and go to
previous menu.
