68P81074C50 3-25
MTSX RSS TUTORIAL
3.3.16 Exit the RSS
Instruction What to Type How to do it/What it Means
Table 3-23. Steps to Exit the RSS
Press Esc to back up to MAIN MENU.
Press F10 then F2 to exit to DOS.
1. Go to MAIN MENU menu.
2. Exit to DOS
3.4 CLONING MORE RADIOS
To clone (copy) radios, they must be of the same model type and version. Cloning applies predominately to
conventional-only radios. To clone trunked radios, you are required to have a system key for each of the trunked
systems programmed into the source radio on file. Most organizations that program trunked radios will not have
access to these keys. The process for cloning conventional and trunked radios, however, is the same.
3.4.1. Desired Features
The desired features are the exact same ones listed in the first tutorial, section 3.2.1
3.4.2 Major Decisions Involved
The major steps for cloning in this tutorial are reduced from six steps in the first tutorial to two steps here.
To program the cloned radio, the approach will be:
a. Pick desired archive file
b. Decide how many radios to clone
3.4.3 Step-by-Step Specific Cloning Instructions
In following section you will:
a. Read into the RSS the specific archive file you want to clone,
b. Actually clone that source file into the current (target) radio's codeplug,
c. Clone the remaining radios the same way, and then
d. Exit the RSS.
