68P81074C50 6-1
SECTION 6. CHANGE/VIEW MENU FUNCTIONS
6.1 INTRODUCTION TO SECTION
This section describes all the functions available from the CHANGE/VIEW MENU. To guide you through these
functions, the following CHANGE/VIEW-related menus and screens are shown with their specific RSS location,
programming procedures from the MAIN MENU, function key descriptions, and field definitions.
NOTE
All functions (supported and unsupported) will be displayed in the menu’s working area. The unsupported functions
(based on the radio’s model or options) will NOT be displayed in the F-key ID area.
6.2 CHANGE/VIEW MENU
RSS LOCATION: At the MAIN MENU, press .
MTSX RSS CHANGE/VIEW
The CHANGE/VIEW MENU is a multi-level menu that is used to view or modify codeplug features and option
configurations. All codeplug parameters are classified as either Radio Configuration, Conventional, or Trunking.
The CHANGE/VIEW MENU functions permit access to each category. Unlike the SERVICE MENU functions, a
codeplug must be loaded into your computer’s memory (via the GET/SAVE/PROGRAM MENU functions) before
you can access the CHANGE/VIEW screens. You may change or view an archive file without a radio connected.
NOTE
If your radio model does not contain a specific feature, you will not be permitted access to the corresponding data
field or screen for that feature. Refer to you radio catalog sheets or radio service manual for radio model descriptions
and features.
MOTOROLA Radio Service Software
MTSX Model:
MAIN:CHANGE/VIEW
Select Function F1 - F10
CHANGE/VIEW MENU
F1 - HELP
F2 -
F3 - Radio Wide Buttons, Switches, Display, Scan, Phone
F4 - Trunking Systems, Personalities, Call Lists, Options
F5 -
F6 - Conventional Systems, Personalities , MDC, Options
F7 -
F8 - Zone/Channel Assignment
F9 -
F10 - EXIT, Return to Main Menu
F1
HELP
F2 F3
RADIO
CONFIG
F4
TRUNK
DATA
F5 F6
CONV
DATA
F7 F8
ZONE/CHN
ASSIGN
F9 F10
EXIT
To Next Page
