IMPORTANT NOTE
The CHANGE VIEW MENU does NOT actually modify the radio codeplug data, but instead, modifies a copy of the
data retrieved from the codeplug or archive file via the GET/SAVE/PROGRAM MENU functions.
After all CHANGE/VIEW modifications are completed, you MUST return to the GET/SAVE/PROGRAM MENU
and program the changes back into the radio or save them to a new archive file. Otherwise, the modifications will
be lost when you turn off your computer or load in another codeplug.
FUNCTION KEY DESCRIPTIONS:
F1 - HELP provides useful information about the currently displayed menu, screen, or field.
F3 - RADIO CONFIG (Radio Configuration) is used to change or view radio parameters and options that affect
the overall radio operation, such as the button settings or default volume setting. Both conventional and
trunking operations are included.
F4 - TRUNK DATA (Trunking Data Configuration) is a multi-level menu used to change or view trunking-only
personalities, systems, etc. Most personality and system data must be changed via the TCMS (trunking
code management system) and can only be viewed. However, all lists (call, scan, phone) may be changed.
For conventional-only models, this function key will not be valid.
F6 - CONV DATA (Conventional Data Configuration) is used to change or view conventional-only parameters
such as personalities, buttons, and MDC signalling. For trunked-only models, this function key will not be
valid.
F8 - ZONE/CHN ASSIGN (Zone/Channel Assignment) is used to assign a group of channels (or talkgroups) to a
particular zone based on some common characteristic such as geographic location, job function, signalling
type, etc.
F10 - EXIT moves the display backward in the RSS tree, one screen or menu at a time.
CHANGE/VIEW MTSX RSS
6-2 68P81074C50
PROGRAMMING PROCEDURE:
1. Press F4 at the MAIN MENU. The CHANGE/VIEW MENU appears.
2. Select the desired function key (F1 - F10).
