MTSX RSS CHANGE/VIEW
68P81074C50 6-17
FUNCTION KEY DESCRIPTIONS:
F1 - HELP provides useful information about the currently displayed menu, screen, or field.
F10 - EXIT moves the display backward in the RSS tree, one screen or menu at a time.
FIELD DEFINITIONS:
Two Position Concentric Position A (Conventional and Trunking)
This field determines the function of the two-position switch when it is in the position marked with the 0 symbol.
MOTOROLA Radio Service Software
MTSX Model:
...CONFIG:FEATURES:SWITCHES
Use UP/DOWN Arrows to Select Choice.
RADIO WIDE SWITCH CONFIGURATION
Switch Labels Conventional Feature Trunking Feature
Two Position Concentric
Position A Blank Scan
Position B Blank Blank
Three Position Toggle
Position A Blank Blank
Position B Blank Blank
Position C PL Disable Blank
F1
HELP
F2 F3 F4 F5 F6 F7 F8 F9 F10
EXIT
6.2.1.2.2 RADIO WIDE SWITCH CONFIGURATION
RSS LOCATION: At the CHANGE/VIEW MENU, press .
PROGRAMMING PROCEDURE:
1. Press F4 at the MAIN MENU. The CHANGE/VIEW MENU appears.
2. Press F3. The RADIO WIDE CONFIGURATION MENU appears.
3. Press F3. The RADIO WIDE FEATURES CONFIGURATION MENU appears.
4. Press F3. The RADIO WIDE SWITCH CONFIGURATION screen appears.
5. Press Tab to select the desired field, or press the desired function key (F1 - F10).
6. If a field is selected, press the up/down arrow keys to select choice or value.
This screen allows you to edit switch settings that pertain to the radio for both trunking and conventional
personalities.
NOTE
Factory defaults for switch assignments are listed in Tables 3-3, 3-13, 3-27, and 3-28.
