CHANGE/VIEW MTSX RSS
6-24 68P81074C50
MOTOROLA Radio Service Software
MTSX Model:
MAIN:CHANGE/VIEW:CONFIG:PHONE:CODES
Enter Code.
DTMF ACCESS/DEACCESS CODES
Num Access Code Deaccess Code
1 *1P# *1P#
F1
HELP
F2
ADD
CODE
F3 F4 F5
DELETE
CODE
F6 F7 F8 F9 F10
EXIT
6.2.1.3.1 DTMF ACCESS/DEACCESS CODES
RSS LOCATION: At the CHANGE/VIEW MENU, press .
This screen allows you to set the Access/Deaccess Code pairs used for the Conventional Phone Operation.
The Access Code is used to keep unauthorized users from using the interconnect system on the repeater. The
Deaccess Code is used to tell the system that the phone call is finished and shorten the wasted air time. These
codes can be selected in the Auto Access Code on the CONVENTIONAL PERSONALITY PHONE OPTIONS
screen (F4/F6/F3/F8).
The valid symbols are as follows:
0-9 Digits
* Asterisk
# Pound
P Pause
Function key descriptions and field definitions are on the following page.
PROGRAMMING PROCEDURE:
1. Press F4 at the MAIN MENU. The CHANGE/VIEW MENU appears.
2. Press F3. The RADIO WIDE CONFIGURATION MENU appears.
3. Press F4. The PHONE CONFIGURATION screen appears.
4. Press F8. The DTMF ACCESS/DEACCESS CODES screen appears.
5. Press Tab to select the desired field, or press the desired function key (F1 - F10).
6. If a field is selected, enter the access or deaccess code via the keyboard.
To Next Page
