MOTOROLA Radio Service Software
MTSX Model:
...TRANSMIT SIGNALLING:HIGH SPEED
Use UP/DOWN Arrows To Adjust Softpot.
F1
HELP
F2 F3 F4 F5 F6
TOGGLE
PTT
F7 F8
PROGRAM
VALUE
F9 F10
EXIT
TRANSMIT SIGNALLING: HIGH SPEED
Frequency Current Value
869.9875 17 New Softpot Value ....................17
Transmitter........Off
0
Min
31
Max
Refer to your radio service manual for the transmit deviation limit alignment: high speed procedure. This
procedure should only be attempted by qualified service personnel.
FUNCTION KEY DESCRIPTIONS:
F1 - HELP provides useful information about the currently displayed menu, screen, or field.
F6 - TOGGLE PTT function will alternately key and dekey the radio being serviced.
F8 - PROGRAM VALUE function will program the selected value into the radio.
F10 - EXIT moves the display backward in the RSS tree, one screen or menu at a time.
New Softpot Value Field Definition
This is the high-speed softpot value for this frequency. The status bar shows the relationship between this setting
and the minimum and maximum settings.
PROGRAMMING PROCEDURE:
1. Press F2 at the MAIN MENU. The SERVICE MENU appears.
2. Press F4. The SIGNALLING ALIGNMENT MENU appears.
3. Press F3. The TRANSMIT SIGNALLING: HIGH SPEED screen appears.
4. Press Tab to select the desired field, or press the desired function key (F1 - F10).
5. If a field is selected, press the up/down arrow keys to select choice or value.
To Next Page
