68P81074C50 4-1
MTSX RSS SERVICE
SECTION 4. SERVICE MENU FUNCTIONS
4.1 RADIO SERVICE VIA THE RSS
Now that the hardware and software installation is complete and the RSS is up and running, you are ready to
personalize the radio(s). The following paragraphs are constructed to guide a qualified service technician through
the allowable alignments and configurations to keep the radio(s) at full capability throughout its design life. This
section describes how to utilize the RSS manual through the various menus and screens to achieve any and all
radio capabilities that may be desired by the radio users.
NOTE
All functions (supported and unsupported) will be displayed in the menu’s working area. The unsupported functions
(based on the radio’s model or options) will NOT be displayed in the F-key ID area.
4.2 SERVICE MENU
RSS LOCATION: At the MAIN MENU, press .
F2
MOTOROLA Radio Service Software
MTSX Model:
MAIN:SERVICE
Select Function F1 - F10.
SERVICE MENU
F1 - HELP
F2 - Transmitter Alignments
F3 - Receiver Alignments
F4 - Signalling Alignments
F5 -
F6 -
F7 -
F8 -
F9 - Controller Board Initialization Program
F10 - Exit, Return to Main Menu
F1
HELP
F2
TX
ALIGN
F3
RX
ALIGN
F4
SIGNAL
ALIGN
F5 F6 F7 F8 F9
CBI
PROGRAM
F10
EXIT
All radio alignment and board replacement procedures are accessed from the SERVICE MENU. A radio must be
connected to your computer via a RIB and cables, and the radio turned on before you will be permitted to access
the service screens.
CAUTION
Do NOT switch radios in the middle of any SERVICE procedure. Always use the EXIT function
key (F10) to return to the MAIN MENU before disconnecting the radio. Improper exits from
service screens may leave the radio in an improperly configured state, resulting in seriously
degraded radio or system performance. Refer to your radio service manual for detailed
service procedures.
All service screens read and program the radio codeplug directly; you do NOT have to use the
GET/SAVE/PROGRAM MENU functions unless you are changing or printing data. You will be prompted at each
service screen to save the new values before exiting the screen.
