CHANGE/VIEW MTSX RSS
6-14 68P81074C50
FUNCTION KEY DESCRIPTIONS:
F1 - HELP provides useful information about the currently displayed menu, screen, or field.
F10 - EXIT moves the display backward in the RSS tree, one screen or menu at a time.
Fields are defined on the following page.
MOTOROLA Radio Service Software
MTSX Model:
...CHANGE/VIEW:CONFIG:FEATURES:BUTTONS
Use UP/DOWN Arrows to Select Choice.
RADIO WIDE BUTTON CONFIGURATION
Button Conventional Trunking
Orange Button Volume Set Tone Nuisance Delete
16 Pos Rotary Chan/Sub Select Channel Select
Side Button 1 (Top) Light Light
Side Button 2 Unprogrammed Phone
Side Button 3 Monitor Private Call
F1
HELP
F2 F3 F4 F5 F6 F7 F8 F9 F10
EXIT
6.2.1.2.1 RADIO WIDE BUTTON CONFIGURATION
RSS LOCATION: At the CHANGE/VIEW MENU, press .
PROGRAMMING PROCEDURE:
1. Press F4 at the MAIN MENU. The CHANGE/VIEW MENU appears.
2. Press F3. The RADIO WIDE CONFIGURATION MENU appears.
3. Press F3. The RADIO WIDE FEATURES CONFIGURATION MENU appears.
4. Press F2. The RADIO WIDE BUTTON CONFIGURATION screen appears.
5. Press Tab to select the desired field, or press the desired function key (F1 - F10).
6. If a field is selected, press the up/down arrow keys to select choice or value.
Depending on your radio version and model number, you will be able to choose from all or some of the functions
listed on the following page.
NOTE
Factory default button assignments are listed in Tables 3-3, 3-13, 3-27, and 3-28.
