CHANGE/VIEW MTSX RSS
6-112 68P81074C50
6.2.3.3.2.2 MDC SYSTEM REMOTE OPTIONS
RSS LOCATION At the CHANGE/VIEW MENU, press .
MOTOROLA Radio Service Software
MTSX Model:
...MDC:SYSTEMS:OPTIONS:REM OPTIONS
Enter or Scroll to Select System.
MDC System................1
MDC SYSTEM REMOTE OPTIONS
Remote Mon/Radio Trace.....................Enabled
Remote Radio Mode .....................Radio Trace
Tx Base Time (sec).......................................10
Rx Base Time (sec) ......................................10
F1
HELP
F2 F3
PREV
SYS
F4
NEXT
SYS
F5 F6 F7 F8 F9
MDC SYS
REMOTE
F10
EXIT
This screen allows you to change/view parameters pertaining to the MDC system remote capabilities of the radio.
FUNCTION KEY DESCRIPTIONS:
F1 - HELP provides useful information about the currently displayed menu, screen, or field.
F3 - PREV SYS (Previous System) allows you to go to the system before the current one.
F4 - NEXT SYS (Next System) allows you to go to the system after the current one.
F9 - MDC SYS (MDC System) MDC SYS REMOTE is used to change and view parameters associated with
MDC System Remote Monitor/Radio Trace features.
F10 - EXIT moves the display backward in the RSS tree, one screen or menu at a time.
Fields are defined on the following page.
PROGRAMMING PROCEDURE:
1. Press F4 at the MAIN MENU. The CHANGE/VIEW MENU appears.
2. Press F6. The CONVENTIONAL MENU appears.
3. Press F4. The MDC CONFIGURATION MENU screen appears.
4. Press F3. The MDC SYSTEM screen appears.
5. Press F9. The MDC SYSTEM OPTIONS screen appears.
5. Press F9. The MDC SYSTEM REMOTE OPTIONS screen appears.
6. Press Tab to select the desired field, or press the desired function key (F1 - F10).
7. If a field is selected, press the UP/DOWN arrow keys to select choice or value.
To Next Page
