MTSX RSS SERVICE
68P81074C50 4-19
4.2.2.2 RATED AUDIO ALIGNMENT
RSS LOCATION: At the SERVICE MENU, press .
Refer to your radio service manual for the rated audio calibration procedure. This procedure should only be
attempted by qualified service personnel.
FUNCTION KEY DESCRIPTIONS:
F1 - HELP provides useful information about the currently displayed menu, screen, or field.
F8 - PROGRAM VALUE function will program the selected value into the radio.
F10 - EXIT moves the display backward in the RSS tree, one screen or menu at a time.
Std Audio Field Definition
This is the rated volume softpot value for this frequency. The status bar shows the relationship between this
setting and the minimum and maximum settings.
Use UP/DOWN Arrows To Adjust Softpot.
RATED AUDIO
Frequency Current Value New Softpot Value
938.0625 Std. Audio.........201 Std. Audio ..............201
F1
HELP
F2 F3 F4 F5 F6 F7 F8
PROGRAM
VALUE
F9 F10
EXIT
MOTOROLA Radio Service Software
MTSX Model:
...RECEIVER ALIGNMENT MENU:RATED AUDIO
0
Min
255
Max
PROGRAMMING PROCEDURE:
1. Press F2 at the MAIN MENU. The SERVICE MENU appears.
2. Press F3. The RECEIVER ALIGNMENT MENU appears.
3. Press F3. The RATED AUDIO screen appears.
4. Press Tab to select the desired field, or press the desired function key (F1 - F10).
5. If a field is selected, press the up/down arrow keys to select choice or value.
