MOTOROLA Radio Service Software
MTSX Model:
...SERVICE:TRANSMITTER ALIGNMENT MENU
Select a Function F1 - F10.
TRANSMITTER ALIGNMENT MENU
F1 - HELP
F2 - Reference Oscillator
F3 - Tx Power
F4 - Tx Deviation Balance (Compensation)
F5 - Tx Deviation Limit
F6 - Tx Deviation Limit: Reference
F7 - Tx VCO Crossover Frequency
F8 - Secure Tx Deviation
F9 -
F10 - Exit, Return to Service Menu
F1
HELP
F2
REF
OSC
F3
TX
PWR
F4
DEV
BAL
F5
DEV
LIMIT
F6
REF
ATTEN
F7
VCO
F8
SECURE
DEV
F9 F10
EXIT
Standard periodic alignment procedures are performed from this menu. Refer to you radio service manual for
alignment procedures. These procedures should only be attempted by qualified service personnel. Failure to
perform alignment procedures properly may result in seriously degraded radio or system performance.
Signalling deviation for DTMF, MDC, Single Tone, Secure and High-Speed trunking data should be checked any
time the radio is serviced and must be adjusted whenever any of the modulation circuitry has been replaced.
Before adjusting signalling deviation, radio compensation/deviation adjustments must be made. No adjustments
are required for DPL, PL, or trunking connect tone deviation.
FUNCTION KEY DESCRIPTIONS:
F1 - HELP provides useful information about the currently displayed menu, screen, or field.
F2 - REF OSC (Reference Oscillator Alignment) This is the working value of the reference oscillator (reference
frequency). Refer to your radio service manual for the transmitter power alignment procedure. This
procedure should only be attempted by qualified service personnel.
F3 - TX PWR (Transmit Power Alignment) Refer to your radio service manual for the transmitter power
alignment procedure. This procedure should only be attempted by qualified service personnel.
PROGRAMMING PROCEDURE:
1. Press F2 at the MAIN MENU. The SERVICE MENU appears.
2. Press F2. The TRANSMITTER ALIGNMENT MENU appears.
3. Select the desired function key (F1 - F10).
