MTSX RSS SERVICE
68P81074C50 4-11
4.2.1.5 TRANSMIT DEVIATION LIMIT ALIGNMENT: REFERENCE SOFTPOT
RSS LOCATION: At the SERVICE MENU, press .
Refer to your radio service manual for the transmit deviation limit alignment reference softpot procedure. This
procedure should only be attempted by qualified service personnel.
FUNCTION KEY DESCRIPTIONS:
F1 - HELP provides useful information about the currently displayed menu, screen, or field.
F6 - TOGGLE PTT function will alternately key and dekey the radio being serviced.
F8 - PROGRAM VALUE function will program the selected value into the radio.
F10 - EXIT moves the display backward in the RSS tree, one screen or menu at a time.
New Softpot Value Channel Spacing Field Definition
This is the reference softpot value for this frequency. The status bar shows the relationship between this setting
and the minimum and maximum settings.
MOTOROLA Radio Service Software
MTSX Model:
...TRANSMIT DEVIATION LIMIT:REFERENCE
Use UP/DOWN Arrows To Adjust Softpot.
TRANSMIT DEVIATION LIMIT: REFERENCE
Current Value New Softpot Value
Frequency Channel Spacing Channel Spacing
869.9875 20KHz ...........114 120KHz.............114
Transmitter ..............Off
F1
HELP
F2 F3 F4 F5 F6
TOGGLE
PTT
F7 F8
PROGRAM
VALUE
F9 F10
EXIT
0
Min
127
Max
PROGRAMMING PROCEDURE:
1. Press F2 at the MAIN MENU. The SERVICE MENU appears.
2. Press F2. The TRANSMITTER ALIGNMENT MENU appears.
3. Press F6. The TRANSMIT DEVIATION LIMIT: REFERENCE screen appears.
4. Press Tab to select the desired field, or press the desired function key (F1 - F10).
5. If a field is selected, press the up/down arrow keys to select choice or value.
To Next Page
