MTSX RSS CHANGE/VIEW
68P81074C50 6-13
MOTOROLA Radio Service Software
MTSX Model:
MAIN:CHANGE/VIEW:CONFIG:FEATURES
Select Function F1 - F10.
RADIO WIDE FEATURES CONFIGURATION MENU
F1 - HELP
F2 - Button/Rotary Configuration
F3 - Switch Configuration
F4 - Menu Item List Configuration
F5 -
F6 -
F7 -
F8 -
F9 -
F10 - EXIT, Return to Radio Wide Configuration Menu
F1
HELP
F2
BUTTON
CONFIG
F3
SWITCH
CONFIG
F4
MENU
ITEM
F5 F6 F7 F8 F9 F10
EXIT
6.2.1.2 RADIO WIDE FEATURES CONFIGURATION MENU
RSS LOCATION: At the CHANGE/VIEW MENU, press .
FUNCTION KEY DESCRIPTIONS:
F1 - HELP provides useful information about the currently displayed menu, screen, or field.
F2 - BUTTON CONFIG (Button Configuration) allows you to edit button assignments for the radio.
F3 - SWITCH CONFIG (Switch Configuration) allows you to edit switch assignments for the radio.
F4 - MENU ITEM allows you to edit menus that appear on the radio’s display. Menu Items are supported on
Front Display models only.
F10 - EXIT moves the display backward in the RSS tree, one screen or menu at a time.
PROGRAMMING PROCEDURE:
1. Press F4 at the MAIN MENU. The CHANGE/VIEW MENU appears.
2. Press F3. The RADIO WIDE CONFIGURATION MENU appears.
3. Press F3. The RADIO WIDE FEATURES CONFIGURATION MENU appears.
4. Select the desired function key (F1 - F10).
This screen is a multi-level menu that is used to change, view, or modify codeplug features and option
configurations that affect both conventional and trunking operation. Typically, when you begin to edit a codeplug,
you will come to this menu and configure the radio-wide options first by working your way through the screens of
this menu. This will allow the options on other screens to reflect the radio-wide options. Some fields will not be
visible if the radio does not support that option.
