This screen allows you to program the radio. A radio interface box (RIB) is required to perform this operation.
TRUNKING RADIOS ONLY:
If you do not have the necessary System Key files and are programming a radio, the serial number of the
attached radio must be identical to the one in the serial number field on the RSS and PROGRAMMING HISTORY
screen. If the serial numbers are different, programming will be aborted. To program this radio you must first read
this radio using the F2 READ function.
FIELD DEFINITION:
Programming Codeplug Blocks
This is the number of blocks that have been programmed. The status bar shows the relative value of the number
of blocks programmed so far compared to the total number of blocks to be programmed.
5.2.5 PROGRAMMING THE RADIO’S CODEPLUG
(Requires RIB)
RSS LOCATION: At the GET/SAVE/PROGRAM MENU, press .
MOTOROLA Radio Service Software
MTSX Model:
MAIN:GET/SAVE/PROG:PROGRAM RADIO
PROGRAM RADIO CODEPLUG
Programming Codeplug Block 1 of 34
F1 F2 F3 F4 F5 F6 F7 F8 F9 F10
PROGRAMMING PROCEDURE:
1. Press F3 at the MAIN MENU. The GET/SAVE/PROGRAM MENU appears.
2. Press F8. The PROGRAM RADIO CODEPLUG screen appears.
0%
100%
F8
GET/SAVE/PROGRAM MTSX RSS
5-12 68P81074C50
