68P81074C50 6-57
FUNCTION KEY DESCRIPTION:
F1 - HELP provides useful information about the currently displayed menu, screen, or field.
F3 - PREV SYS (Previous System) allows you to go to the system before the current one.
F4 - NEXT SYS (Next System) allows you to go to the system after the current one.
F5 - ONE TOUCH (when enabled) is used to change and view the Trunking.System One Touch Features and
the One Touch Indices assocated with the Features.
F6 - STATUS ALIAS (when enabled) is used to change and view the parameters associated with Trunking
System Status Alias.
F7 - MSG ALIAS (Message Alias)\ (when enabled) is used to change and view the parameters associated with
Trunking System Message Alias.
F8 - SITE ALIAS (when enabled) is used to change and view the parametersassociated with Trunking System
Site Alias.
F10 - EXIT moves the display backward in the RSS tree, one screen or menu at a time.
MTSX RSS CHANGE/VIEW
6.2.2.3 TRUNKING SYSTEM OPTIONS
RSS LOCATION: At the CHANGE/VIEW MENU, press .
MOTOROLA Radio Service Software
MTSX Model:
...CHANGE/VIEW:TRUNKING:SYSTEM:OPTIONS
Enter or Scroll to Select System.
System..........................1 TRUNKING SYSTEM OPTIONS
Tx Power Select....................................High Phone DTMF Timing ..................................1
Trunk Repeater Offset......................45 MHz Initial Delay (msec)..............................250
Digit Duration (msec)...........................150
Channel Assgn. Type ....................Domestic Inter Digit Delay (msec).......................100
Splinter Channel.............................Disabled Hot DTMF Timing.......................................1
Rx Modulation.....................2 Level Receive Initial Delay (msec)..............................250
Digit Duration (msec)...........................150
Inter Digit Delay (msec).......................100
Status Aliasing ................................Enabled
Channel Bandwidth ........................25.0 kHz Message Aliasing............................Enabled
ISW Retry Timer.............................Disabled Site Aliasing ....................................Enabled
F1
HELP
F2 F3
PREV
SYS
F4
NEXT
SYS
F5
ONE
TOUCH
F6
STATUS
ALIAS
F7
MSG
ALIAS
F8
SITE
ALIAS
F9 F10
EXIT
PROGRAMMING PROCEDURE:
1. Press F4 at the MAIN MENU. The CHANGE/VIEW MENU appears.
2. Press F4. The TRUNKING MENU appears.
3. Press F3. The TRUNKING SYSTEM screen appears.
4 Press F9. The TRUNKING SYSTEM OPTIONS screen appears.
5. Press Tab to select the desired field, or press the desired function key (F1 - F10).
6. If a field is selected, press the UP/DOWN arrow keys to select choice or value.
To Next Page
