CHANGE/VIEW MTSX RSS
6-120 68P81074C50
This screen contains Singletone List information. It allows you to modify the frequencies for the Singletone List.
FUNCTION KEY DESCRIPTIONS:
F1 - HELP provides useful information about the currently displayed menu, screen, or field.
F2 - ADD TONE allows you to add a tone.
F5 - DELETE TONE allows you to delete a tone.
F10 - EXIT moves the display backward in the RSS tree, one screen or menu at a time.
FIELD DEFINITIONS:
Tone (Hz)
Use the Up/Down arrow keys to select or enter directly the desired tone frequency. The defined tones can be
used o a per-conventional personality basis in the CONV PER RAC OPTIONS screen (from Main Menu,
F4,F6,F3,F9,F7) by enabling the Repeater Access field. The field "Singletone (HZ)" will contain a tone from this
list. The valid range is 300-3000 Hz in 0.1 Hz increments. The factory default is 300 Hz.
6.2.3.4.2 SINGLETONE LIST
RSS LOCATION At the CHANGE/VIEW MENU, press .
PROGRAMMING PROCEDURE:
1. Press F4 at the MAIN MENU. The CHANGE/VIEW MENU appears.
2. Press F6. The CONVENTIONAL MENU appears.
3. Press F7. The AUXILIARY MENU appears.
4. Press F3. The SINGLETONE LIST screen appears
5. Press Tab to select the desired field, or press the desired function key (F1 - F10).
6. Press the UP/DOWN arrow keys to select choice or value.
MOTOROLA Radio Service Software
MTSX Model:
CONV:AUX:SINGLETONE LIST
Enter or Scroll to Select Frequency.
SINGLETONE LIST
# Tone (Hz # Tone (Hz
1 300.0
F1
HELP
F2
ADD
TONE
F3 F4 F5
DELETE
TONE
F6 F7 F8 F9 F10
EXIT
To Next Page
