MTSX RSS GETTING STARTED
68P81074C50 2-35
2.12.1 How to Read the Codeplug
A. Connect the radio to the computer as shown in Figure 2-1. If you are not already at the MAIN MENU,
press any key at the BANNER screen.
B. From the MAIN MENU press F3; the GET/SAVE/PROGRAM MENU will be displayed.
2.12.1.1 Reading the Codeplug
You may read the codeplug from the radio or from the archive disk. After reading, the codeplug will be checked
for valid serial number, model number, checksums, etc.
2.12.1.2 Reading Codeplug Data from the Radio
Turn the radio on and press F2. A series of status messages will appear in the upper right corner of the screen. If
a communication error occurs, a pop up window will be displayed. If no errors occur, the center of the screen will
display the progress of the codeplug read. The read process will take approximately one minute. After the
codeplug is read, the GET/SAVE/PROGRAM MENU will be displayed.
2.12.1.3 Reading Disk Codeplug Files
Press F3 from the GET/SAVE/PROGRAM MENU. The Disk File Names screen will be displayed. An archive
path and the list of files in that path will be displayed. By default, the path will be the corresponding archive path
specified on the Paths and Port screen. If you want to retrieve a file from another path, press F2, type in the path
name, and then press Enter. The names of the files in the new path will be displayed.
To verify the model number and serial number of the codeplug file before reading it, select the desired file by
pressing Enter, Tab, Shift, or the arrow keys until the desired filename is highlighted.
To retrieve a selected file, press F8. The selected file will be retrieved, validated, and placed in computer
memory. The read process will be displayed on the screen.
