MTSX RSS SERVICE
68P81074C50 4-13
4.2.1.7 SECURE TRANSMIT DEVIATION
RSS LOCATION: At the SERVICE MENU, press .
FUNCTION KEY DESCRIPTIONS:
F1 - HELP provides useful information about the currently displayed menu, screen, or field.
F6 - TOGGLE PTT - function will alternately key and dekey the radio being serviced
F8 - PROGRAM VALUE function will program the selected value into the radio.
F10 - EXIT moves the display backward in the RSS tree, one screen or menu at a time.
New Softpot Value Field Definition
This is the secure transmit deviation softpot value for this frequency. The status bar shows the relationship
between this setting and the minimum and maximum settings.
PROGRAMMING PROCEDURE:
1. Press F2 at the MAIN MENU. The SERVICE MENU appears.
2. Press F2. The TRANSMIT ALIGNMENT MENU appears.
3. Press F8. The SECURE TRANSMIT DEVIATION screen appears.
4. Press Tab to select the desired field, or press the desired function key (F1 - F10).
5. If a field is selected, press the up/down arrow keys to select choice or value.
MOTOROLA Radio Service Software
MTSX Model:
MAIN:SERVICE:TX ALIGN:SECURE TX DEV
Use UP/DOWN Arrows To Adjust Softpot.
SECURE TRANSMIT DEVIATION
Frequency Current Value
490.0250 110 New Softpot Value ..............110
Transmitter . . . .Off
F1
HELP
F2 F3 F4 F5 F6
TOGGLE
PTT
F7 F8
PROGRAM
VALUE
F9 F10
EXIT
0
Min
127
Max
Refer to your radio service manual for the secure transmit deviation alignment procedures. This procedure
should only be attempted by a qualified service personnel. Secure transmit deviation should be checked any
time the radio is serviced and must be adjusted whenever any of the modulation circuitry has been replaced.
